What is FADGI? Everything You Need to Know About Federal Imaging Standards

Key Takeaways

  • FADGI is a federal initiative, started in 2007, that defines sustainable standards for digitized and born-digital records.
  • Compliance is measured on a one-to-four star scale, and FADGI recommends digitizing to at least three stars when possible; Modern Textual Records - MTR (based on 3 Star parameters) use a separate pass/fail specification.
  • FADGI mainly applies to federal agencies (through NARA and OMB) but is increasingly adopted by state and local government and regulated industries.
  • The federal rule took effect June 5, 2023, and agencies must manage all permanent records electronically by June 30, 2024.
  • Meeting FADGI requires FADGI-capable scanners, authorized analysis software and targets, and validated processes.

FADGI (the Federal Agencies Digital Guidelines Initiative) is a set of U.S. federal standards for digitizing records and cultural materials at consistent, preservation-grade quality. Even as government agencies go paperless, there's more to digitization than simply scanning and uploading — it's critical to preserve important files in their historical context, and that requires the right processes and tools. Whether you manage archival records, oversee digitization projects, or procure scanning equipment, understanding FADGI compliance is essential for meeting federal requirements and preserving valuable materials for future generations.

What is FADGI and Why Was It Created?

FADGI was created in 2007 "to articulate common sustainable practices and guidelines for digitized and born-digital historical, archival, and cultural content." In other words, FADGI guidelines help standardize best practices and ensure consistent quality control throughout the archival digitization process. This makes it easier for future readers to observe the preserved records with great detail and accuracy to the original.

Generally speaking, quality is the most important metric when digitizing files. For documents and images, this might mean removing any flaws that didn't appear originally. However, in some cases, those markings tell a story that shouldn't be lost in the digital transformation. As Vaughn Minger, Manager, National Sales - East at PFU America, Inc. puts it, "There's a lot more to FADGI-compliant scanning than just copying images. Historical documents have additional details that tell us a lot about them. Every watermark, blemish, or artifact tells a story, and it's important to tell that story. It's not just about image quality, as modern scanners often remove these imperfections. It's about preserving a piece of history, which means archiving these documents in their true forms."

Who and What Does FADGI Affect?

FADGI affects any permanent record stored by the National Archives and Records Administration (NARA) or the Office of Management and Budget (OMB). That means these guidelines primarily affect government organizations working to digitize historically significant files.

FADGI has two separate subgroups: the Still Image Working Group and the Audio-Visual Working Group. These groups have different goals and deliverables, but the core objective is the same: preserving important files as they make the transition from paper to digital files.

The National Archives and Records Administration (NARA) determined in June 2019 that, to be accepted by NARA, permanent records including ancestral records, maps, fine art, and manuscripts held by the federal government must comply with a minimum 3-star FADGI rating. The federal rule took effect on June 5, 2023. By June 30, 2024, federal agencies were required to manage all permanent records in an electronic format.

FADGI distinguishes between two main guideline sets:

  • Modern Textual Records (MTR): Covers common text-based documents such as correspondence, reports, and forms — the benchmark for most federal records digitization.
  • Cultural heritage: Addresses rare materials, photographs, artwork, and other items that require more rigorous capture specifications.

While compliance is mandatory only for federal agencies, adoption is growing among state and local government, universities, libraries, museums, and regulated industries like finance and healthcare that want to apply recognized preservation standards.

What Do the FADGI Star Ratings Mean?

FADGI rates digitization quality on a scale of one to four stars, where more stars mean closer conformance to the FADGI Technical Guidelines.

  • One star: Reference quality — appropriate where the goal is to locate the original rather than reproduce it; it does not conform to the ISO 19264 standard.
  • Two stars: The minimally acceptable rating for most professional digitization activity.
  • Three stars: A very good professional image that is appropriate for most uses.
  • Four stars: The best imaging practical today and the current state of the art in image capture; FADGI notes it is an appropriate goal for smaller-scope projects, and cautions against imaging to four-star level for all but the most sophisticated imaging programs.

FADGI recommends digitizing to at least three stars when possible, however, modern textual records (MTR) are handled differently. This category was added in 2023 using specifications from NARA, and federal agencies use it when digitizing permanent records. MTR is a single conformance specification rather than a star rating. It is based on three-star aim points but relaxes some requirements, allows grayscale, and requires a minimum of 300 ppi (no lower than 294 ppi after scale tolerance).

How is FADGI Calculated?

While the FADGI star system is fairly straightforward, understanding how to meet those standards is more complex. FADGI's Technical Guidelines evaluate a set of image-quality parameters to determine a star rating. Among them:

  • Sampling frequency: In technical terms, sampling frequency "measures the potential spatial resolution of a digital image." This is calculated as pixels per inch (PPI) or per millimeter. Sampling frequency helps archivists determine the size and quality of the original image.
  • White balance error: This measures "color neutrality" in the original digital file. FADGI notes that "the definition of neutral is not universal," but "Digitization workflows are increasingly adopting the L*a*b* color mode" that defines neutral as 0 on the a* and b* axes.
  • Lightness uniformity: Images should have a fairly even field of illumination, which may require the use of FADGI-compliant software to achieve. FADGI warns against "aggressive corrections" that can introduce artifacts into the final image.
  • Sharpening: Many digital imaging tools automatically sharpen images to artificially enhance their quality, but a sharper image isn't the same as one with higher resolution. While sharpening isn't inherently a negative, it can irreversibly alter an image. Therefore, FADGI warns to use this feature sparingly.
  • Noise: If you've ever seen what looked like a grainy filter on an old photograph, you've seen one of the most common examples of noise. Where most digitization tools aim to remove noise, FADGI-compliant files should use noise reduction in moderation.

How Do You Become FADGI Compliant?

Becoming FADGI compliant means pairing FADGI-capable hardware with authorized analysis software and repeatable, validated processes. Follow these three steps to become FADGI compliant:

  1. Ask vendors for proof. Request test results from GoldenThread analysis software showing that scanned images meet your required star level, and trust only technology that is available and tested today. You can also ask if any third party verification has been completed. Here are the results of the FADGI compliance test of the fi-8950 conducted by Keypoint Intelligence.
  2. Use authorized software and calibration targets. The GoldenThread analysis software and printed targets from Image Science Associates measure image quality objectively against the FADGI scale.
  3. Choose an implementation partner with FADGI expertise. Work with a vendor that offers in-house setup guidance, documentation, and ongoing support to help you reach and maintain compliance.

Are There Penalties for Non-Compliance?

The federal digitization rule sets records-management requirements rather than monetary or punitive penalties, so there are currently no fines for not meeting FADGI guidelines. Non-compliance still results in a lot of extra work and wasted time, however. Files that don't comply may be rejected and have to undergo the digitization process again. Invest in the proper technology before undergoing digitization to avoid creating bottlenecks in the archiving process.

What Technology Is Needed to Achieve FADGI Compliance?

Government agencies affected by these guidelines will need FADGI-compliant records management software and FADGI capable scanner hardware. Records management software streamlines the maintenance of digital files. Competent software should record the data of creation, as well as any updates to the original upload. It should also make these files easy to identify and retrieve.

When it comes to scanner technology, the strategic move is to find hardware that's already FADGI-capable. This way, you won't have to analyze every individual specification to see if it meets the standards for noise reduction, sharpness, white balance error, and so on. The right scanner should also be fast and efficient.

Our Recommendation: FADGI-Capable fi Series Scanners

Those in the market for a high-speed document scanner have no shortage of options, but achieving FADGI compliance isn't quite so simple. We take great pride in having spent the last 50+ years researching, designing, and developing some of the most advanced and powerful electronics in the world, including our professional grade fi and SP series of scanners, which are ahead of the curve when it comes to preserving historical documents.

Built to purpose for the most demanding document handling jobs, fi and SP scanners are capable of processing tens of thousands of pages per day at the highest levels of accuracy. Their intuitive integration capabilities with all existing work suites minimize time-to-value for businesses looking to invest in tools that will pay dividends for years to come.

The current Ricoh fi Series FADGI bundles — including the fi-8950, fi-8930, fi-8820, fi-8700, fi-7600 and fi-8190 — ship calibrated for FADGI MTR before delivery and include GoldenThread device-level targets plus ScanCare support. These Ricoh fi Series scanners are capable of fulfilling FADGI MTR standards when calibrated accordingly, making it far easier to meet these guidelines.

Learn more about our best FADGI compliant scanners here.

Note: Information and external links are provided for your convenience and for educational purposes only, and shall not be construed, or relied upon, as legal or financial advice. PFU America, Inc. makes no representations about the contents, features, or specifications on such third-party sites, software, and/or offerings (collectively “Third-Party Offerings”) and shall not be responsible for any loss or damage that may arise from your use of such Third-Party Offerings. Please consult with a licensed professional regarding your specific situation as regulations may be subject to change.

Frequently Asked Questions

No — only federal agencies must comply, though private organizations increasingly adopt FADGI to meet industry expectations and preservation goals.

FADGI favors open, standardized formats — its Technical Guidelines list TIFF, JPEG 2000, and PDF/A as acceptable master formats, with formats like JPEG commonly used for access copies.

MTR is the FADGI guideline set for common text-based documents, and it is the quality benchmark most records-digitization projects are measured against.

No — FADGI does not review, certify, or endorse commercial products; scanners are described as "FADGI-capable" when calibrated to meet the guidelines.
